Description
Take on rugged trails with the officially licensed Ford Raptor F150 1/8 scale crawler by TractionHobby. This high-detail RC truck combines scale realism with serious crawling performance, thanks to a robust metal chassis, independent front suspension, rear solid axle with lockable diffs, and a feature-packed electronic system.
Key Features:
- Official Ford License: Realistic 1.5mm vacuum-formed PC body with scale details in Silver, Blue, Black, Red, or White.
- Heavy-Duty Chassis: 1.5mm steel C-channel frame rails for durability.
- Suspension Setup: Front independent suspension and rear solid axle with CNC bridge covers, supporting differential locks.
- Advanced Drivetrain: Switchable 2WD/4WD, selectable front/rear/4WD modes via transmitter.
- Integrated Transmission: Two-speed gearbox with reverse, metal gears, and selectable drive modes.
- Powerful Electronics: RS775 brushed motor with 880 high-voltage splash-proof ESC, XT60 connector.
- 23KG High-Torque Servo: CNC multi-link steering system with metal servo horn.
- Premium Suspension: Full-metal coilover shocks filled with 550CST oil (Front: 81mm / Rear: 93mm).
- Metal Drivetrain: 7mm metal driveshafts, 5mm alloy steel links, metal gears throughout.
- Scale Detail: Functional LED light kit, wipers, door handles, interior details, removable bed, quick-release body system.
- 2.2” CNC Aluminum Wheels: Fitted with KO2-style 120mm × 42mm tires for aggressive grip.
Electronic System:
- Transmitter: Small Elephant DDF-350, 10-channel 2.4GHz with color screen and gyro assist.
- Motor: RS775 Mabuchi brushed (21000 rpm), upgradable to 1/8 brushless.
- ESC: Custom 880 high-voltage splash-proof with 7.4V BEC.
- Servos: 1 × 23KG TH1623 steering, 4 × 4KG TH1036 function servos for shifting, front/rear diff locks, drive selection.
- Lighting: Combined LED and SMD light set, LED roof bar (battery/charger not included).
Dimensions and Specs:
- Body Size: 695 × 280 × 255 mm (packaged 770 × 360 × 330 mm)
- Wheelbase: 421 mm
- Ground Clearance: 222 mm
- Track Width: 374 mm
- Approach / Breakover / Departure Angles: 36° / 32° / 27°
- Net/Gross/Volume Weight: 6.5kg / 10.2kg / 19kg
- Battery Bay Size: 150 × 46 × 40 mm (2–4S compatible)
Radio Channel Configuration :
- CH1: Steering
- CH2: Throttle
- CH3: Lights
- CH4: High/Low Gear
- CH7: Drive Mode (FWD/4WD/RWD)
- CH9: Front Diff Lock
- CH10: Rear Diff Lock
- CH5-6-8: Spare/Customizable
Note: Battery and charger are not included.
